Automatic blister packaging machine
Product Video
Specification
| Model | MY-PM2020-S |
| Frequency | 50KHz |
| Power | 3000w |
| Voltage | 220v/110v |
| Weight | 150kg |
| Machine Size | 900*1050*1400mm |
| Warranty | 1 year |
| Production deficiency | 8-12times/min |
Features
High frequency welding machine with automatic loading and unloading device, With automatic manipulator.
Mingyang Ultrasonic has professionally specialized in plastic blister packaging equipment for many years. The rotary plastic blister packing machine is mainly suitable in the packaging of toys, stationery, foods, commodity, cosmetics, hardware etc, and it is for user group with demands on product varieties and saving cost.
1. High-cycle loop optimization design, using digital anti-jamming circuit.
2. Adopting the oscillator of Japan Toshiba,the output is stable and reliable.
3. High sensitivity spark protection system can effectively prevent the damage of the mold.
4. The rotating disc is driven by a motor divider, and the continuous point type can be selected.
5. The power is pneumatic and the pressure is high. Three pairs of lower molds work in turn, with high production efficiency.
6. The machine has large power and large platen area.
7. The operation is easy and flexible: Tidy paper card, product, blister before putting into the mold manually, turn rotary table for sealing, put the product, three station cycle time is between four seconds to six seconds, depends on the operating experience.
8. Packaged products are various: The machine is mainly suitable for the user group with demands on product varieties and saving cost.
9. The machine is the priority in blister packaging field.
10. This model is a small machine, four wheels to move freely.
Competitive Advantage
△ High efficiency---It only takes 0.1-3 seconds at each time.
△ High strength---Weld joints can withstand big tensile force and high pressure.
△ High quality---Weld joints are water-tight and air-proof; airtight operation is guaranteed.
△ Economy---Keep costs down and reduce manpower by getting rid of screws and glue.
Factory Show
Certification
Applications
Rotary plastic blister packaging machine is suitable for plastic such as PET/PETG/GAG/PVC and other double-sided blister packaging, plastic paper card packaging, APET soft plastic box indentation folding box, toothbrush packaging, dolls, leather straps, EVA cloth leather, leather, OPP, TPU, PU, etc. Ir can be used in toys, stationery, foods, commodity, cosmetics, hardware etc.
This machine uses the pulse fever from the mould/die with heating elements. It seals paper card and blister perfectly, and the sealed products are not only with moisture proof and dust proof function, but also with eye-catching appearance.
