Single Tank Ultrasonic Cleaning Machine
Specification
| Model | MY-S2890-S |
| Frequency | 28 KHz |
| Power | 300-1800w |
| Voltage | 220v |
| Net Weight | 100kg |
| Machine Size | 500x350x350mm |
| Oscillating plate size | 300x180x100mm |
| Warranty | 1 year |
Features
Principle of ultrasonic cleaning：
Ultrasonic cleaning systems send high frequency sound waves ripping through an ultrasonic cleaning solution leaving superheated bubbles in the waves' wake. When these bubbles, called cavitation, collapse, the heat and energy of their implosions work with the specially formulated ultrasonic cleaning solution to remove dirt, oils, residue and oxidation from the surface of the contaminated item.
Single tank ultrasonic cleaner for electronics industry machine
1.A new generation of computer chip, dual display frequency current, more powerful
2.Using a pulse width control, more accurate and more stable output power adjustment.
3.The automatic adjustment and automatic frequency tracking, so that the tone machine more stable easier
4.Enhanced circuit protection functions: over-temperature protection and over current protection, so that more reliable
5.The new circuit structure optimization design, the whole rational layout and maintenance more convenient.
Applications
Ultrasonic cleaning machine can be widely used in cleaning metal , mold, DPF, car engine block parts, engine block, hardware, mould, tool, screw, nut, PCB, circuit, golf ball, glassware, cylinder, printer etc.
Factory Show
Certification
FAQ
A: Yes, we can. The mould could be customized based on your samples, the voltage can be 110V or 220V, the plug can be replaced with yours before shipment.
A: Please provide the material, size of your product and your welding requirements, such as waterproof, tight air, etc. You'd better provide product 3D drawings , and we can help to check if the drawings need to be changed. So that the plastic product design could meet the requirements of ultrasonic welding technology.
